Horyong BMK-403 ECO

Preţ excl. TVA

POA

Compnay LOGO
Images6
Horyong BMK-403 ECO Alte macarale
Horyong BMK-403 ECO Alte macarale
Horyong BMK-403 ECO Alte macarale
FavoriteFavorit
shareDistribuie
Save searchSalvare căutare
Imprima

INFORMAȚII

Grup de produse
Alte macarale
Marca /model
Horyong BMK-403 ECO
Anul fabricatiei
2018
Ore de utilizare
287 h
Locatia masinii
Duisburg, Nordrhein-Westfalen
Tara
Germania
Nivel general
1
2
3
4
5
Mascus ID
A65059D6

DETALII

Număr de proprietari anteriori
1
Greutate neta
4.019 kg
Capacitate maxima de ridicare
4.200 kg
Max lifting capacity at end of jib
3.000 kg
Boom length
680 cm
Luffing jib
220 cm
Jib length of crane
680 cm
Înaltime maxima de ridicare
1.020 cm
Hook height of crane - horizontal jib
840 cm
Hook height of crane - luffed jib
221 cm
Upper engine
see chassis
Upper hours
200 h
Original colour
Silber-Grün
Carrier engine
Electric
Dimensiuni transport (Lxlxî)
435000 x 157000 x 205000 mm
Tip portbagaj
Cu volan
Brand anvelope
NM-Bereifung
Calitate cauciucuri fata
90
Condiţia anvelopelor anterioare
90
Tara de productie
Corea de Sud
Termen de livrare
FCA, CPT, EXW
Certificate
CE, TÜV
Atasamente
Hakenflasche 1-rollig
Accesorii
Hook blocks
Documente
Traglasttabellen-Horyong-BMK-403-ECO-Hauptausleger-abgestutzt.pdf
Alte informaţii
Battery industrial yard crane HORYONG BMK-403 ECO, used unit battery drive, CE 2018, approx. 287 working hours Pick+carry and Carry deck TECHNICAL DETAILS: max. lifting capacity 4,2 t x 0,9 m max. load pick + carry 2,9 t max. load on carry deck 2,5 t max. working range 6,7 m (8,2 m with fly jib) max. hook height: 8,41 m (10,2 m with fly jib) DIMENSIONS & WEIGHT length 4.350 mm width 1.570 mm, height 2.050 mm total weight of crane: 4.019 kg outrigger base: 2.330 mm x 3.330 mm CRANE EQUIPMENT: telescopic main boom 3,07 bis 6,8 m, fully hydraulic, 3 sections fly jib with sheave head 2,2 m, max. lifting capacity 1,2 t, angel 0°, 25°, 50° one winch 360° slewing range unlimited Electronical Safe Load Indicator System Rayco Wylie i4500 working range limiter optical and voice warning system working light, emergency stop, round-about light hook block 1-sheave, max. 4,0 t lifting capacity drive 4 x 2 x 2 Carry-Deck for goods, size 1,55 m², max. load 2,9 t 3 pieces pipe holders / transport holders 4-point hydraulic outriggers, front and rear electric engine with batteries, 2x 10 kW, 72V / 300 Ah, rechargable batteries, integrated battery charger max. speed of crane is 6 km/h 4x non marking tires open crane driver cabin with lattice protection roof, operation panel The electric yard crane crane is in good working condition and can be ideally used inside hall areas where exhausts are vorbidden, The unit is immediately available ex our yard and can also be rented for jobsites in Germany.Afiseaza mai multe

Mini & Mobile Cranes Körner GmbH

Alte Kaserne 23 47249 Duisburg Nordrhein-Westfalen Germania
